Cross-Cut machine F-3

Simple cross cuting machine for production of planks applied in pallet production.

Example options of cut:

Technical data

Dimensions
  • length 2020 mm
  • width 3400 mm
  • height 1400 mm
Weight 800 kg
Dimensions of infeed workpiece
  • length within 600 - 2550 mm
  • width max. 200 mm
  • thickness max. 40 mm
Main motors power 3 x 3 kW
Power demand 10 kW
Power supply 230/400 V
Thickness of cut setting manual
Circular blade diameter 300 mm

Optional equipment

  • option with 2 blades
  • option with 4 blades
  • option with 5 blades
  • transverse redler conveyor for extraction of wastes and sawdust from under the machine
