CZ-1/XL Sawmill PREMIERE
Sawmill developed in cooperation with our long-term customers, who for many years have been working on our basic sawmill CZ-1/ZM. CZ-1/XL is our response to market requirements for industrial machine that would work faster and will be more efficient. Additionally, this device may be also equipped with a wide range of optional equipment.
Technical data
| Dimensions |
|
| Weight | 2700 kg |
| Log diameter | 1000 mm (band saw guiding rollers inter-distance 850 mm) |
| Length of cut (standard) | 6000 mm |
| Main motor power | 20 kW |
| Power supply | 400 V (3-phases) |
| Cutting head |
|
| Band wheels diameter | 700 mm |
| Band saw specification |
|
| Blade tension roller slide | electrical - adjustable by joystick |
| Thickness of cut setting | controller ISP-010 |
| Hydraulic |
|
| Operator control panel | stationary, fixed by the hydraulic control panel |
| Capacity per hour | up to 3,5 m3 |
Optional equipment
- bed extension 4 m long (length of cut 10 m)
- debarker
- chain log turner
- claw log turner
- leveling roller, standard (up/down)
- leveling roller with drive (up/down & forward/backward)
- hydraulic clamp (3-cylinders) dual-column
- hydraulic scissor grip clamp
- loading arm – basic length 1,7 m
- laser
- operator seat
- boards drag-back system (max. length of elements 6 m)
- sideway board drop system (3 - arms, width 2,5 m)
- loading ramp RZ/CZ-1
- low-level loading ramp (3 chain tracks)
- belt conveyor for boards collection, length 6 m
- belt conveyor for boards collection, length 1,4 m with hydraulic lift
- operator’s cabin
- monitoring
